Specifications displayed may vary based on manufacturer year, model change and tire size. If you require certain specifications please contact an HR2 representative.
Lift Height
43'
Horizontal Outreach
30' 5"
Lift Capacity
9,000 lbs
Lift Lower Speed
9 sec
Extend Retract Speed
15/13 sec
Overall Width
97"
Stowed Height
98"
Stowed Length
237"
Wheelbase
135"
Ground Clearance
17"
Weight
24,912 lbs
Drive Speed 2WD 4WD
19 mph
Turning Radius 2WD/4WD (Outside)
12'
Fuel Type
Diesel
Fuel Capacity
38.3 gal
Brakes
Inboard wet disc brake on front and rear axles, parking brakes are wet disc spring applied hydraulic release on front axle
Web SKU
943
